DH100F

  • 71~100kWh
  • 280Ah LFP battery

All-in-one air cooling energy storage system with 71~100kWh available for a single unit, suitable for big house and small commercial and industrial applications. Supports full scenario with functions like timed scheduling, peak shaving, PV self generation and consumption and so on.

DH100F Product Advantage Features

  • undefined

    Full-scenario
    All-in-one multifunctional integration, supporting PV and generator access, grid-to-off-grid switching

  • undefined

    Ultimate security
    Preventative fire strategy with three-level detection and TMG which ensure active firefighting remains effective in the event of a power outage

  • undefined

    Flexible expansion
    71~100kwh capacity available for single unit; Reserved DC expansion interface; Support AC expansion

  • zhinengyouhua-29.svg

    Intelligent and efficient
    280Ah LFP battery with high energy density. EMS Intelligent control

  • undefined

    low-cost
    Modular design,backward and bottom output, reduce infrastructure cost

undefined

Technical Specifications

  • 002.1974fuben-938.png
  • 002.1975fuben.png
  • 002.2050fuben.png
  • ProductDH100F All-in-one PV+ESS
    System capacity
    71kWh
    Battery Type
    LFP (280Ah)
    Rated current
    140A(0.5C)
    Battery voltage range232~288V
    Dimension (W*D*H)
    725*1200*2258mm
    Weight
    ≈1500kg
    Ingress protection
    IP55
    Cooling method
    Air cooling
    Number of PACKOne cluster/5 modules
  • Product
    DH100F All-in-one PV+ESS
    System capacity
    86kWh
    Battery Type
    LFP (280Ah)
    Rated current
    140A(0.5C)
    Battery voltage range
    278.4~345.6V
    Dimension (W*D*H)
    725*1200*2258mm
    Weight
    ≈1500kg
    Ingress protection
    IP55
    Cooling method
    Air cooling
    Number of PACK
    One cluster/6 modules
  • Product
    DH100F All-in-one PV+ESS
    System capacity
    100kWh
    Battery Type
    LFP (280Ah)
    Rated current
    140A(0.5C)
    Battery voltage range
    324.8~403.2V
    Dimension (W*D*H)
    725*1200*2258mm
    Weight
    ≈1500kg
    Ingress protection
    IP55
    Cooling method
    Air cooling
    Number of PACK
    One cluster/7 modules
