DH200Y
- 100kW/232kWh
- Supports up to 10 units in parallel
Dyness' first high security, high energy density DC1000V liquid cooling all-in-one energy storage system, compact structure design reduces space, 232kWh in a single cabinet, supports AC and DC side expansion at any time, zero parallel capacity loss.
Product Features
-
Safe and Reliable
Pack cell pressure monitoring, triple-level fire suppression, active discharge, and explosion-proof design -
High Energy Density
Occupies an area of 1.58 m², energy density up to 147kWh/m2 -
Intelligent and Efficient
Intelligent Precision Liquid Cooling with Cluster-Level Temperature Difference Under 3°C -
High-level Protection
C5 corrosion protection grade, IP65+Pack, and IP65 PCS -
Minimalist Operation and Maintenance
Pre-maintenance plan, fully modular design, minimalist operation and maintenance -
Flexible Expansion
Single-unit reserved expansion interface, Flexibly support DC expansion；Supports up to 10 units in parallel, expandable to 2.3MWh
Technical Parameters
-
Product DH200Y Dimension (W*D*H) 1055*1645*2398mm Weight 2600±100kg
Max.Efficiency ≥90%（TBD）
Liquid-cooling Power
2.5kW (Cooling), 2kW (Heating)
Temperature -20~50℃ (Derating above 45℃)
Humidity 0~95%RH (Non-condensing)
Ingress Protection IP55 Anti-corrosion Grade C3/C5 Cooling Method
PACK Liquid-cooling + PCS Air-cooling
Noise ≤75dB Elevation 3000m (Derating above 2000m)
Display Touch screen Fire Protection Aerosol/Perfluorohexanone
Communication Ethernet/4G/RS485
Certification
CQC, CE, TUV
Battery
Battery Type LFP (LiFePO4) Battery Capacity 280Ah PACK Configuration 1P52S PACK Quantity 5 PACK/Cluster
Voltage Range 754~936V Rated Current 140A（0.5C） Max. Current 160A Nominal Capacity
232kWh AC (On Grid)
Rated Power 100kW AC Maximum Current 145A
AC Rated Voltage 400Vac
Wiring Method 3P4L+PE Frequency 50Hz
THDi <3%（Rating power） Max. Number Of Parallel Expansions 12
