STACK100

15.36-76.8kWh
Max expandable to 921.6kWh

The Dyness STACK100 energy storage system is widely used in energy storage sector. It adopts modular design and can be used for residential and C&I applications. The reliable LiFeP04 technology ensures maximum safety and a longer life cycle.

Product Inquiry

Product Features

Each PACK has an independent fire extinguishing device.
1C discharge, built-in air-cooling system
Single system capacity: 15.36-76.8kwh, expandable to a maximum of 921.6kWh in parallel
Convenient installation and Total installation time ≤1h
Flexible space layout ability

Technical Specifications

Product Model	STACK100
Battery Module Type	LiFePO4
Module Voltage/Capacity	51.2V/100Ah
System Energy Range	15.36-76.8kWh
Cycle Life	Unlimited cycles/10 Years
Signal Module Weight	47Kg
Max. Single Cluster Dimension	5913901700mm

Modular Design, Plug-and-Play

Frameless stacking cuts space & costs.
47kg module, 30-min quick install.
Built-in square steel frame ensures stable load-bearing.

Scalable, Multi-scenario

Supports 12-cluster parallel.
15kWh-921kWh energy range.
restaurants, warehouses, farms, and more.
3-year modular flexibility, scalable for cost savings.

1C Charge/Discharge, Noticeable Efficiency Boost

Modules independently charge/discharge at max 86.4kW, ensuring business runs smoothly. Charging at lows, discharging at peaks cuts electricity costs.

5S Auto Fire Extinguishing, Thoughtful Protection

Each module includes an aerosol fire extinguisher that quickly acts within 5 seconds of detecting high temp, minimizing fire risks and ensuring safety.

New Internal Cooling Design Boosts Lifespan By 20%.

Our battery module's unique vents keep temps steady (≤3℃ difference), keeping cells cool indoors and extending battery life by 20%.
