Tower
- up to 21.31kWh
- Stackable design with self-adaptive modules
The upgraded Tower Series is tailor-made for large residential application. Stackable design with self-adaptive modules, five energy choices of up to 21.31kWh with parallel connection available, advanced LiFePO4 technology, remote upgrade, high waterproof level and good cooling function... Whatever you need, Dyness Tower Series is there to meet your requirements.
Product Features
-
APP Monitoring (optional)
Real-time monitoring & Remote upgrade available -
Self-adaption
Auto configuration -
Easy Installation
Stackable design, wireless connection -
High Protection Level
Indoor & outdoor installations -
Wide Compatibility
Matching with leading inverters
Technical Specifications
-
Model Tower T7 Battery Module Type LiFePO4 Battery Module Quantity 2 Nominal Energy 7.10kWh Operating Voltage 168~219V Nominal Voltage 192V Nominal Capacity 37Ah
Max. Continuous Charge/Discharge Power 4.26kW Recommended Depth of Discharge (DOD) 95% Dimensions [W*D*H] 504*380*700 mm Net Weight [kg] 105kg Charging Temperature Range 0~50℃ Discharging Temperature Range -10~50℃ Communication CAN/RS485/RS232 Cycle life ≥6000 Cycles Protection Level IP54 Color White Alarms Overcharge/Overdischarge/Overcurrent/Overtemperature/Short Circuit Pros Can be used in both off-grid and hybrid setups, compact design, modular expansion Battery Module Name HV9637 Expansion Max. 12 towers can be connected in parallel Certification UN38.3/CE-EMC/IEC62040/IEC62619/IEC62477/IEC60730/IEC63056/UKCA/CEC Accredited/UL1973/VDE2510-50 Compatible Inverters Ingeteam/Kostal/Goodwe/Solis/SAJ/Sinexcel/Atess/Deye/Sunways/Ecactus etc. -
Model Tower T10 Battery Module Type LiFePO4 Battery Module Quantity 3 Nominal Energy 10.66kWh Operating Voltage 252~328V Nominal Voltage 288V Nominal Capacity 37Ah
Max. Continuous Charge/Discharge Power 6.39kW Recommended Depth of Discharge (DOD) 95% Dimensions [W*D*H] 504*380*900 mm Net Weight [kg] 146kg Charging Temperature Range 0~50℃ Discharging Temperature Range -10~50℃ Communication CAN/RS485/RS232 Cycle life ≥6000 Cycles Protection Level IP54 Color White Alarms Overcharge/Overdischarge/Overcurrent/Overtemperature/Short Circuit Pros Can be used in both off-grid and hybrid setups, compact design, modular expansion Battery Module Name HV9637 Expansion Max. 12 towers can be connected in parallel Certification UN38.3/CE-EMC/IEC62040/IEC62619/IEC62477/IEC60730/IEC63056/UKCA/CEC Accredited/UL1973/VDE2510-50 Compatible Inverters Ingeteam/Kostal/Goodwe/Solis/SAJ/Sinexcel/Atess/Deye/Sunways/Ecactus etc. -
Model Tower T14 Battery Module Type LiFePO4 Battery Module Quantity 4 Nominal Energy 14.21kWh Operating Voltage 336~438V Nominal Voltage 384V Nominal Capacity 37Ah
Max. Continuous Charge/Discharge Power 8.52kW Recommended Depth of Discharge (DOD) 95% Dimensions [W*D*H] 504*380*1100 mm Net Weight [kg] 187kg Charging Temperature Range 0~50℃ Discharging Temperature Range -10~50℃ Communication CAN/RS485/RS232 Cycle life ≥6000 Cycles Protection Level IP54 Color White Alarms Overcharge/Overdischarge/Overcurrent/Overtemperature/Short Circuit Pros Can be used in both off-grid and hybrid setups, compact design, modular expansion Battery Module Name HV9637 Expansion Max. 12 towers can be connected in parallel Certification UN38.3/CE-EMC/IEC62040/IEC62619/IEC62477/IEC60730/IEC63056/UKCA/CEC Accredited/UL1973/VDE2510-50 Compatible Inverters Ingeteam/Kostal/Goodwe/Solis/SAJ/Sinexcel/Atess/Deye/Sunways/Ecactus etc. -
Model Tower T17 Battery Module Type LiFePO4 Battery Module Quantity 5 Nominal Energy 17.76kWh Operating Voltage 420~547V Nominal Voltage 480V Nominal Capacity 37Ah
Max. Continuous Charge/Discharge Power 10.65kW Recommended Depth of Discharge (DOD) 95% Dimensions [W*D*H] 504*380*1300 mm Net Weight [kg] 228kg Charging Temperature Range 0~50℃ Discharging Temperature Range -10~50℃ Communication CAN/RS485/RS232 Cycle life ≥6000 Cycles Protection Level IP54 Color White Alarms Overcharge/Overdischarge/Overcurrent/Overtemperature/Short Circuit Pros Can be used in both off-grid and hybrid setups, compact design, modular expansion Battery Module Name HV9637 Expansion Max. 12 towers can be connected in parallel Certification UN38.3/CE-EMC/IEC62040/IEC62619/IEC62477/IEC60730/IEC63056/UKCA/CEC Accredited/UL1973/VDE2510-50 Compatible Inverters Ingeteam/Kostal/Goodwe/Solis/SAJ/Sinexcel/Atess/Deye/Sunways/Ecactus etc. -
Model Tower T21 Battery Module Type LiFePO4 Battery Module Quantity 6 Nominal Energy 21.31kWh Operating Voltage 504~657V Nominal Voltage 576V Nominal Capacity 37Ah
Max. Continuous Charge/Discharge Power 12.78kW Recommended Depth of Discharge (DOD) 95% Dimensions [W*D*H] 504*380*1500 mm Net Weight [kg] 269kg Charging Temperature Range 0~50℃ Discharging Temperature Range -10~50℃ Communication CAN/RS485/RS232 Cycle life ≥6000 Cycles Protection Level IP54 Color White Alarms Overcharge/Overdischarge/Overcurrent/Overtemperature/Short Circuit Pros Can be used in both off-grid and hybrid setups, compact design, modular expansion Battery Module Name HV9637 Expansion Max. 12 towers can be connected in parallel Certification UN38.3/CE-EMC/IEC62040/IEC62619/IEC62477/IEC60730/IEC63056/UKCA/CEC Accredited/UL1973/VDE2510-50 Compatible Inverters Ingeteam/Kostal/Goodwe/Solis/SAJ/Sinexcel/Atess/Deye/Sunways/Ecactus etc.
