We have launched our  Battery Energy Storage System to Europe,Australia, South America, Africa, Europe with moderate price and top-class quality.

Home Energy Storage Systems - Low voltage

Popular items

DL5.0C

DYNESS DL5.0C adopts economic design, and is tailor-made for residential & small commercial application. This LFP battery module supports remote update and APP monitoring,and provides multiple installation methods. It is scalable from 5.12 -256 kWh (max. 50 modules in parallel), providing various energy storage options to meet different requirements.

Buy Now >
Specifications
Product Characters
Data Download
Model DL5.0C
Battery Type LiFePO4
Nominal Battery Energy 5.12 kWh
Nominal Capacity 100Ah
Nominal Voltage 51.2V
Operating Voltage 44.8 ~ 57.6V
Recomended Charge & Discharge C Rate 0.5C
Maximum Discharge C rate 1C
Recommended Charge/Discharge Current 50A
Max. Power Charge/Discharge Current Charge 75A/Discharge 100A
Peak Power Charge/Discharge Current 110A (15s)
Depth of Discharge (DOD) 90%
Net Weight 54 kg
Dimension[W*D*H] 558*545*150 mm
Charging Temp. Range 0~55°C/-20~55°C (with heating function)
Discharging Temp. Range -20~55℃
Communication CAN/RS485/RS232
Cycle Life[1] ≥6000 Cycles
Protection Level lP20
Expansion up to 50 units in parallel
Pros Can be used in both off-grid and hybrid setups, compact design
Certification & Safety Standard UN38.3/CE-EMC/IEC62619/CEI-021

[1]Test conditions: 0.2C Charging/Discharging, @25℃, 90% DOD

APP Monitoring (optional)Module DesignVarious Mounting MethodsHigh Safety LFPWide Compatibility
Real-time monitoring& Remote upgrade available Flexible expansionWall-mounted, floor-standing and stackCell level monitoring and balancingMatching with leading inverters
Introduction of Dyness DL5.0C battery module
Low voltage Battery
DL5.0C

Product information

• Data sheet
DL5.0C
- EN
• Data sheet
DL5.0C
- CN
• Data sheet
DL5.0C
- PT

Certification

• CE-
DL5.0C
• CEI-021-
DL5.0C
• EN 62619-
DL5.0C
• IEC 62619-
DL5.0C
• UL 1973-
DL5.0C
• MSDS-
DL5.0C
• UN38.3-
DL5.0C
• TUV Certificate IEC62040-
DL5.0C
• 62040-
DL5.0C

Installation instrument

• Installation instrument #1• Installation instrument #2

Warranty

• Warranty-
DL5.0C
-EN
